Proximity Sensors - Industrial
Banner EngineeringS18UUA
Banner Engineering S18UUA is an ultrasonic sensor. Specifications include a sensing range of 30–300 mm, Analog Output: 0 to 10 V DC or 4 to 20 mA, depending on output, IP67 protection, 10V ~ 30V supply, M18, ABS/PC housing, and an operating temperature of -20°C to 60°C.
Engineering Specifications
9 of 13 fields available · 69%Verified specifications6 of 9 verified specifications with source evidence
Verification date not recordedView source document
Sensor TypeUltrasonicVerified · High · Page 1
Sensing MethodNot specified
Sensing Range30.0 – 300.0 mmVerified · High · Page 1
Manufacturer datasheetHighPage 1
Evidence: labeled distance range with explicit units
Excerpt: “30 mm to 300 mm”
Extracted Sep 1, 2026View source
Output TypeAnalog Output: 0 to 10 V DC or 4 to 20 mA, depending onVerified · High · Page 1
Manufacturer datasheetHighPage 1
Excerpt: “Analog Output: 0 to 10 V DC or 4 to 20 mA, depending on”
Extracted Sep 6, 2026View source
Supply Voltage10V ~ 30V
IP RatingIP67Verified · Medium · Page 6
Manufacturer datasheetMediumPage 6
Evidence: consistent across candidate regions
Excerpt: “IP67”
Extracted Sep 6, 2026View source
Housing MaterialABS/PCVerified · High · Page 1
Housing TypeM18
Operating Temperature-20°C to 60°C
Switching FrequencyNot specified
Response Time2.5 msVerified · High · Page 1
Current ConsumptionNot specified
AccuracyNot specified
