Sensors, Transducers
Telemecanique SensorsXX2V3A1PFM12
Telemecanique Sensors XX2V3A1PFM12 is an ultrasonic sensor. Specifications include a sensing range of 8000 mm (range 298.7–8001 mm), PNP output, IP67 protection, 10-28V supply, M30, ULTEM housing, and an operating temperature of -20°C to 60°C.
Engineering Specifications
11 of 13 fields available · 85%Verified specifications8 of 11 verified specifications with source evidence
Verification date not recordedView source document
Sensor TypeUltrasonicVerified · High · Page 1
Sensing MethodNot specified
Sensing Distance8000.0 mm (range 298.7–8001.0 mm)
Output TypePNPVerified · High · Page 1
Supply Voltage10-28VVerified · High · Page 1
Manufacturer datasheetHighPage 1
Evidence: labeled voltage with V unit
Excerpt: “10…28 V DC”
Extracted Sep 6, 2026View source
IP RatingIP67Verified · High · Page 1
Manufacturer datasheetHighPage 1
Evidence: labeled ingress-protection context
Excerpt: “IP67”
Extracted Sep 6, 2026View source
Housing MaterialULTEMVerified · High · Page 1
Housing TypeM30
Operating Temperature-20°C to 60°C
Switching FrequencyNot specified
Response Time150 msVerified · High · Page 1
Current Consumption100 mAVerified · High · Page 1
Accuracy2.54%Verified · High · Page 1
Where to Buy
Best Price
Mouser
$442.27Availability unknown
Verify current stock at the retailer before ordering.
All retailer offers (2)
Can’t find the configuration or quantity you need? Request a sensor.
Related Sensors — Potential alternatives
Other Ultrasonic sensors you may consider, including options from other manufacturers.
| MPN | Manufacturer | Description | Range | Price |
|---|---|---|---|---|
| VM18PNCQ | Telemecanique | ULT SEN 300KHZ 12V/24V | 508.0 mm | $145.75 |
| VM1PNOQ | Telemecanique | ULT SEN 300KHZ 12V/24V | 508.0 mm | $153.04 |
| XXA30B1PM12 | Telemecanique | ULTRASONIC SENSORS XX, ULTRASONI | 155.4 mm | $353.97 |
| XXA30P1PM12 | Telemecanique | ULTRASONIC SENSORS XX, ULTRASONI | 155.4 mm | $308.75 |
| XXA30S1PM12 | Telemecanique | ULTRASONIC SENSORS XX, ULTRASONI | 155.4 mm | $368.97 |
