Proximity Sensors - Industrial
Telemecanique SensorsXSDA600519
Telemecanique Sensors XSDA600519 is an inductive sensor. Specifications include a sensing range of 60 mm, 1 NO or 1 NC programmable output, IP67 protection, 12 ~ 240V AC supply, Form 80 x 80 x 40, Plastic housing, and an operating temperature of -25°C to 70°C.
Engineering Specifications
9 of 13 fields available · 69%Verified specifications7 of 9 verified specifications with source evidence
Verification date not recordedView source document
Sensor TypeInductiveVerified · High · Page 1
Sensing MethodNot specified
Sensing Distance60.0 mm
Output Type1 NO or 1 NC programmableVerified · High · Page 1
Manufacturer datasheetHighPage 1
Excerpt: “1 NO or 1 NC programmable”
Extracted Sep 7, 2026View source
Supply Voltage12 ~ 240V AC
IP RatingIP67Verified · High · Page 1
Manufacturer datasheetHighPage 1
Evidence: labeled ingress-protection context
Excerpt: “IP67”
Extracted Sep 7, 2026View source
Housing MaterialPlasticVerified · High · Page 1
Housing TypeForm 80 x 80 x 40Verified · High · Page 1
Operating Temperature-25°C to 70°CVerified · High · Page 1
Manufacturer datasheetHighPage 1
Evidence: labeled range with explicit °C/°F/K unit
Excerpt: “-13…158 °F”
Extracted Sep 1, 2026View source
Switching Frequency10 HzVerified · High · Page 1
Response TimeNot specified
Current ConsumptionNot specified
AccuracyNot specified
Where to Buy
Best Price
Mouser
$258.653 In Stock · checked Sep 4, 2026
Verify current stock at the retailer before ordering.
All retailer offers (2)
Can’t find the configuration or quantity you need? Request a sensor.
Related Sensors — Potential alternatives
Other Inductive sensors you may consider, including options from other manufacturers.
| MPN | Manufacturer | Description | Range | Price |
|---|---|---|---|---|
| XSDH607339TF | Telemecanique | INDUCTIVE SENSOR 30V .1MA+OPTION | 60.0 mm | $422.48 |
| XS7C4A1DPG13 | Telemecanique | INDUCTIVE PROXIMITY SENSORS XS, | 15.0 mm | $233.92 |
| XS7C4A1MPN12 | Telemecanique | INDUCTIVE SENSOR, XS7, 40X40X117 | 15.0 mm | $213.53 |
| XSDA400519H7 | Telemecanique | INDUCTIVE PROXIMITY SENSORS XS, | 40.0 mm | $268.87 |
| XS106B3PBM8 | Telemecanique | INDUCTIVE SENSOR 36VDC 200MA XS | 2.5 mm | $122.95 |
